EV Charging Cables

---

Our Focus is the Sustainability of our Products

Premium Quality – Competitive Pricing:
Our range of charging cables is made to a superior specification right here in the UK, they include both single and three phase, in either a straight, coiled (which generally sit above the ground) or combination cable depending on requirement.

We produce all our cable with the expectation that it will be coiled, to support this we use a higher volume together with a finer specification of copper stranding within the cores.  We also twist the cores together prior to sheathing which enables the finished cable to be twisted and bent to a much higher degree making it much more resistant to strain and twisting damage than standard straight laid cable.  The bend radius on the single phase cable is 25.00 mm – which is extremely flexible.

Once the main cores are assembled, a process known as "extrusion" takes place to ensure the cables are of the highest quality and will provide reliable charging, many manufacturers opt for the cheaper and less reliable method (but sometimes aesthetically more pleasing) of tube extrusion, but our cables are assembled using the superior method of pressure extrusion.

Pressure extrusion forces molten plastic directly onto the conductors, creating a tighter bond, stronger adhesion, better core retention, and less risk of water ingress. It also provides a more thorough solution  filling the smallest of gaps improving mechanical strength and durability.

In contrast, Tube extrusion may offer slightly better uniformity, but it can result in a looser fit, weaker adhesion, reduced core retention, and less effective protection in tougher service conditions.

Pressure extrusion may occasionally show minor bumps or blemishes on the cable surface, but these are cosmetic only and do not affect the working performance of the cable, overall providing a more robust and reliable long-term product.
